N3505-2B
| Manufacturer | |
| Description | Connector Accessories Short Latch Polychlorinated Terphenyl Headers & Wire Housings EJECTOR LATCHES BLK SHORT W/PINS EJECTOR LATCHES BLK SHORT W/PINS EJECTOR LATCH, SHORT, WITH PIN Ejector/latch with bolts PU=2 ST, N3505-2B, 3M |
| Category |
Business
| Part # Aliases | 05111165642 80000900441 | Product Category | Headers & Wire Housings |
| Standard Package | Bulk | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85366930 |
Electrical
| Voltage Rating | 1 kV | Current Rating (Max) | 5 A |
Mechanical
| Weight | 0 | Contact Finish | Gold |
| Contact Material | Copper Alloy | Housing Material | Polyester |
| Termination Style | PCB | ||
Product Info
| Type | Short Latch | Series | 3000 |
| Product Type | Accessories | Accessory Type | Ejector Latch |
| RF Family/Standard | N3505 | For Use With/Related Products | 3000 Series |
Environmental
| Operating Temperature | - 55 C to + 105 C | ||
