950422-8200-AR-TR
| Manufacturer | |
| Description | Conn Socket Strip SKT 22 POS 2mm Solder RA SMD T/R Headers & Wire Housings 22P BD MNT SKT 2R RA SMT 10U AU 2 mm x 2 mm Right Angle, Surface Mount CONN SOCKET 22POS 2MM R/A SMD |
| Category |
Business
| Other Names | 3M9284CT | Part # Aliases | 05111104587 DE500036319 |
| Product Category | Headers & Wire Housings | Standard Package | Tape & Reel |
Compliance
| RoHS | RoHS Compliant | ||
Mechanical
| Color | Black | Pitch | 2 mm |
| Packaging | Reel | Row Spacing | 0.079" (2.00mm) |
| Termination | Solder | Contact Type | Female Socket |
| Mounting Type | Surface Mount, Right Angle | Connector Type | Receptacle |
| Contact Finish | Gold Over Nickel | Number of Rows | 2 |
| Number of Contacts | 22 | Number of Positions | 22 |
| Contact Finish Thickness | Flash | ||
Product Info
| Type | Socket Strip | Gender | SKT |
| Number of Positions Loaded | All | ||
