9120-4500PL

Manufacturer	3M Company
Description	Conn Board to Board SKT 20 POS 2.54mm Solder ST Thru-Hole .100" Ã .100" Centerbump Polarization with Straight Solder Tails, 20 - 64 contacts CONN SOCKET 20POS .100" STR GOLD Polarized Boardmount Socket (20 pos) .100 centerline straight solder tails Headers & Wire Housings 20P STRT PLRZD SKT SOCKET, PCB, 20WAY PolarizedBoardmountSocket(20pos).100centerlinestraightsoldertails
Category	Connector SolutionsBoard to Board ConnectorsBoard-to-Board Connectors

对参数有疑问？问 AI 助手

Business

Part # Aliases	54745226295 JE150318838	Product Category	Headers & Wire Housings
Standard Package	Bulk	Factory Pack Quantity	100

Compliance

RoHS

Lead free / Vendor undefined

Tariff No

85369010

Electrical

Current Rating (Max)

:1A

Mechanical

Color	Gray	Pitch	2.54 mm
Weight	0.01	Packaging	Bulk
Row Spacing	0.100" (2.54mm)	Termination	Solder
Contact Type	Female Socket	Lead Spacing	:2.54mm
Mounting Type	Through Hole	Connector Type	Receptacle
Contact Finish	Gold Over Nickel	Number of Rows	2
Contact Material	:Copper	Termination Style	Through Hole
1st Contact Gender	Socket (Female)	Number of Contacts	20
Contact Termination	:Through Hole Vertical	Number of Positions	20
Contact Finish Thickness	12µin (0.30µm)

Product Info

Type	Board to Board	Gender	SKT
Series	9100	Features	Polarizing Key
Product Type	Receptacles / Sockets - PCB	Number of Positions Loaded	All

Environmental

Operating Temperature

:105°C

Documents & Media

Online Document

91xx-4500PL

PDF Document

95058.pdf
