点击放大查看

62C96-1201EC

Manufacturer	3M Company
Description	Conn DIN 41612 SKT 96 POS 2.54mm IDT RA Cable Mount Type C (Rows A & C or A, B & C Filled) CONN SOCKET 96POS DIN W/FLANGE 96/96 way IDC cable socket w/mount ear DIN 41612 Connectors 96P IDC EUROSOCKET HIGH DENSITY W/FLANG SOCKET, IDC, DIN41612, 96WAY IDCDIN4161296/96W
Category	Connector SolutionsBackplane ConnectorsDIN 41612

对参数有疑问？问 AI 助手

Business

Part # Aliases	05113841139 DE610020203	Product Category	DIN 41612 Connectors
Standard Package	Bulk	Factory Pack Quantity	50

Compliance

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Approval Agency	:CSA, UL	RoHS Compliance	Yes
Material Flammability Rating	UL94 V-0

Electrical

Range deg/s	:3M - 62CXX Series	Voltage Rating	:500V
Voltage - Breakdown	:1kV	Current Rating (Max)	1A
Insulation Resistance	:1000Gohm	Contact Rating (Current)	:1A

Mechanical

Depth	10.6 mm	Pitch	2.54 mm
Height	11.6 mm	Weight	14.225601 oz
Material	:Glass Reinforced Polyester	Packaging	Bulk
Termination	IDT	Lead Spacing	:2.54mm
Housing Color	Gray	Mounting Type	Cable Mount
Connector Type	Receptacle, Female Sockets	Contact Finish	Gold Over Nickel
Mounting Style	Cable	Number of Rows	3
Package / Case	:DIN41612	Contact Material	Copper Alloy
Housing Material	PBT	Termination Style	Solder
Number of Contacts	96	Contact Termination	:IDC / IDT
Number of Positions	96	Material - Insulation	Polybutylene Terephthalate (PBT), Polyester, Glass Filled
Contact Finish Thickness	30µin (0.76µm)	1st Connector Mounting Type	:Flange

Product Info

Type	DIN 41612	Style	C
Gender	Female	Series	DIN
Features	Feed Through	Number of Positions Loaded	All

Environmental

Level, Class

Operating Temperature

-55°C ~ 125°C

Documents & Media

Online Document

mediawebserver?66666UuZjcFSLXTt4Xfy58s6EVuQEcuZgVs6EVs6E666666--

PDF Document

1788390.pdf
