8516-4500PL

Manufacturer	3M Company
Description	ヘッダ & ワイヤハウジング 16P STRAIGHT SOCKET POLARIZED STRAIGHT BM SOCKET 16P .100" Ã .100" Centerbump Polarization with Straight Solder Tails, 10 - 64 contacts CONN SOCKET PCB VERT 16POS .1" 3M 2.54mm 16 Way 2 Row Straight PCB Socket Through Hole Socket Strip Headers & Wire Housings 16P STRAIGHT SOCKET POLARIZED SOCKET, PCB, 16WAY PolarizedBoardmountSocket(16pos).100centerlinestraightsoldertails Socket; IDC; female; PIN:16; straight; THT; gold plated; 3A; 2.54mm 3M 8500 系列 2行 16路直 2.54mm节距通孔印刷电路板插座, 插座板 16P BM SOCKET STRAIGHT 2ROW
Category	Connector SolutionsBoard to Board ConnectorsBoard-to-Board Connectors

对参数有疑问？问 AI 助手

Business

MOQ	100	Unit Pack	100
Part # Aliases	54745226286 JE150318739	Product Category	Headers & Wire Housings
Standard Package	100	Factory Pack Quantity	100

Compliance

RoHS	Lead free / RoHS Compliant	Tariff No	85369010
Leadfree Defin	RoHS-conform	Approval Agency	UL E68080
Material Flammability Rating	:UL94V-0

Electrical

Voltage Rating	1000V	Number of Poles	:16
Voltage - Working	:350V	Current Rating (Max)	1A
Insulation Resistance	:1000Mohm

Mechanical

Color	Gray	Pitch	0.100" (2.54mm)
Weight	0.002	Material	:Glass Filled Polyester
Packaging	Bulk	Cable Exit	NO
Orientation	STRAIGHT	Row Spacing	0.100" (2.54mm)
Termination	Press-Fit	Contact Type	Female Socket
Lead Spacing	:2.54mm	Pitch - Post	2.54mm
Mounting Type	Through Hole	Connector Type	Receptacle
Contact Finish	Gold	Number of Rows	2
Contact Material	Copper Alloy	Housing Material	PBT
Package Quantity	100	Connector - Cable	socket
Termination Style	Through Hole	1st Contact Gender	Socket (Female)
Color - Connectors	:Grey	Number of Contacts	16
Contact Termination	:Through Hole Vertical	Number of Positions	16
Contact Finish Thickness	12µin (0.30µm)	Contact Material - Plating	FLASHGOLD
1st Connector Mounting Feature	2x8

Product Info

Spg	100	Type	Socket Strip
Gender	:Receptacle	Series	8500
Features	Polarizing Key	Polarity	:Bump
Matchcode	85164500PL	CAD Drawing	3D CAD Model
Product Type	Receptacles / Sockets - PCB	Number of Units	1
Standard Leadtime	13 weeks	Other Specifications	NO
Number of Positions Loaded	All

Environmental

Mating Cycles

Operating Temperature

-55 TO 105°C

Documents & Media

PDF Document

74893.pdf
