151220-7422-TB
| Manufacturer | |
| Description | Headers & Wire Housings 20P R/A SOLDER TAIL 2 mm à 2 mm Solder Tail Straight & Right Angle, Surfacemount Straight CONN 20POS2MM HEADER RT/DUAL GLD Header;Pak20PinStrip;CopperAlloy;GlassFilledPolyester;20;1.5A |
| Category |
Business
| Standard Package | 500 | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | Standards | ULListed |
| Approval Agency | cUL,UL | RoHS Compliance | No |
| Material Flammability Rating | UL94V-0 | ||
Electrical
| Voltage - Rated | 500VDC | Current Rating (Max) | 1.5A |
| Insulation Resistance | 5x10^9Ohms(Max.)@250VDC | ||
Mechanical
| Color | Black | Pitch | 0.079" (2.00mm) |
| Plating | Gold-MIL-G-45204,TypeII,GradeC | Packaging | Bulk |
| Row Spacing | 0.079" (2.00mm) | Termination | Solder |
| Contact Type | Male Pin | Length - Pin | 0.152" |
| Mounting Type | Through Hole, Right Angle | Angle of Throw | Right |
| Connector Type | Header, Unshrouded | Contact Finish | Gold |
| Number of Rows | 2 | Terminal Style | RightAngleSolderTail |
| Contact Material | CopperAlloy | Housing Material | GlassFilledPolyester |
| Length - Overall | 0.787" | Primary Material | InterconnectSystem |
| Size / Dimension | 0.768in.+0.005in.,-0.010in.Lx0.155in.Wx0.059in.H | Pin Hole Diameter | 0.0787" |
| Number of Contacts | 20 | Number of Positions | 20 |
| Material - Insulation | GlassFilledPolyester | Contact Length - Mating | 0.152" (3.86mm) |
| Contact Finish Thickness | 30µin (0.76µm) | ||
Product Info
| Type | PCBPlug | Manufacturer | 1512Series |
| Number of Positions Loaded | All | ||
