EC09E rotary encoder Series
alpsVertical mechanical rotary encoders with 15 pulses and 30 detents
The EC09E series from Alps Alpine is a vertical mechanical rotary encoder designed for precision applications requiring accurate position feedback. These encoders come with 15 pulses per revolution and 30 detents, providing a reliable way to measure rotational motion with high resolution and repeatability. If you're working on machinery that needs precise control and monitoring, such as industrial robots, CNC machines, or automated assembly lines, these encoders are a great fit.
One thing worth noting is their robust construction. Being vertical, they are less prone to lateral forces, making them ideal for environments where stability is crucial. Engineers tend to reach for this when they need an encoder that can handle harsh conditions without compromising on performance. Another practical benefit is their ease of installation due to their compact design, which allows for space-constrained applications. Overall, the EC09E series offers a balanced mix of reliability and functionality, making them a solid choice for a wide range of mechanical systems.
Series Images (7)
Documents & Media
Frequently Asked Questions
EC09E rotary encoder - Part List
5 parts in total| Mfr Part # | Quantity Available | Price | Category | Mounting Type | Encoder Type | Pulses per Revolution | Packaging | Shaft Detail | Shaft Diameter | Mounting Hole Diameter | Rotational Life (Cycles Min) | Product | RoHS | SVHC | Tariff No | Resolution | Number of Bits | Number of Channels | Torque | Weight | Number of Positions | Length - Shaft and Bearing | Positions Per Level | Other Specifications | Operating Temperature | Termination Style | Product Category | Factory Pack Quantity | Output | Voltage - Supply | Detent | Built in Switch | Rad Hardened | Terminal Type | Mounting Style | Mechanical Life | Operating Temperature - Junction | Type | Card Standard | Series | Orientation | Output Type | Part Status | Manufacturer | Actuator Type | DigiKey Programmable |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EC09E1520406 WITHOUT SWITCH Alps 15 Pulse Incremental Mechanical Rotary Encoder with a 6mm Flat Shaft (Not Indexed), Through Hole Encoders 5Volts Through Hole ENCODER,VERTICAL, 9MM, 30DET, 15PPR 15mmVerticalencoder15Pulses30DET Incremental Type Encoder • Structure: Vertical • Number of Detent: 30 • Number of Pulse: 15 • Actuator Length: 15mm • Push-on Switch: Without Alps 15位置 增量 机械式旋转编码器, 6 mm直径 扁平轴 (没有索引), 通孔 alps electric | 10 | 8: $2.8132 | - | Through Hole | Incremental | 15 | Tray | Flat | 6 mm | 1 mm, 1.2 mm, 2 mm | :15000 | Mechanical Encoders | RoHS Compliant | :No SVHC (20-Jun-2013) | 85365015 | 15 PPR | :15 | :2 | :8mN-m | 0.00244 | 30 | :15mm | Not Indexed | No Switch | - 40 C to + 85 C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
EC09E1524404 WITH 1.5 SWITCH Alps 15 Pulse Incremental Mechanical Rotary Encoder with a 6mm Flat Shaft (Not Indexed), Through Hole Encoders 9mm 15 RES 30 DTENT ENCODER,VERTICAL, 9MM, 30DET, 15PPR Incremental Type Encoder • Structure: Vertical • Number of Detent: 30 • Number of Pulse: 15 • Actuator Length: 20mm • Push-on Switch: With Alps 15位置 增量 机械式旋转编码器, 6 mm直径 扁平轴 (没有索引), 通孔 alps electric | 10 | 5: $12.6578 | - | Through Hole | Incremental | 15 | Tray | Flat | 6 mm | 1 mm, 1.2 mm, 2 mm | :15000 | Mechanical Encoders | RoHS Compliant | :No SVHC (20-Jun-2013) | 85365015 | 15 PPR | :15 | :2 | :8mN-m | 0.00276 | 30 | :20mm | Not Indexed | Yes | - 40 C to + 85 C | Through Hole | Encoders | 700 | Quadrature | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 EC09E1524405 WITH 0.5 SWITCH Alps 15 Pulse Incremental Mechanical Rotary Encoder with a 6mm Flat Shaft, Through Hole Alps 15 Pulse Incremental Mechanical Rotary Encoder with a 6mm Flat Shaft (Not Indexed), Through Hole Encoders 9mm 15 RES 30 DTENT EC09E1524405 ENCODER,VERTICAL, 9MM, 30DET, 15PPR Incremental Type Encoder • Structure: Vertical • Number of Detent: 30 • Number of Pulse: 15 • Actuator Length: 20mm • Push-on Switch: With Alps 15位置 增量 机械式旋转编码器, 6 mm直径 扁平轴 (没有索引), 通孔 alps electric | 10 | 1: $2.4923 | - | Through Hole | Incremental | 15 | Tray | Flat | 6 mm | 1 mm, 1.2 mm, 2 mm | :15000 | Mechanical Encoders | Compliant | :No SVHC (20-Jun-2013) | 85365015 | 15 PPR | :15 | 2 | :8mN-m | 0.00268 | 30 | :20mm | Not Indexed | Yes | - 40 C to + 85 C | Through Hole | Encoders | 700 | Quadrature | 5 | Yes | Yes | No | PC Pins | Through Hole | 15000 | 85C | - | - | - | - | - | - | - | - | - |
EC09E1520402 Encoders 9mm 15 RES 30 DTENT Alps 15 Pulse Incremental Mechanical Rotary Encoder with a 6mm Flat Shaft, Through Hole Encoders • 9mm Size Metal Shaft Encoder EC09E Series • Type: Metal shaft • Operating Section: Flat • Length of Operating Section: 20mm • Detent Torque: 85mNm • Number of Detent: 30 • Resolution: 15-pulses • Operating Direction: Vertical • Push-on Switch: Without • Travel of Push-on Switch: - ALPS | 1116 | 1: $7.3571 | - | Through Hole | Incremental | 15 | - | Flat | 6 mm | 1 mm, 1.2 mm, 2 mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Encoders | Incremental Type Encoder | - | - | - | - | - | - | - |
 EC09E1524418 Buy now, ships today. EC09E1524418 - Rotary Encoder Incremental 15 Quadrature (Incremental) Vertical from Alps Alpine. View datasheets, pricing and availability from DigiKey now! ALPS ELECTRIC | 466 | 1: $6.9306 | - | PCB, Through Hole | Incremental | 15 | Tray | - | - | - | 15K | - | - | - | - | - | - | - | - | - | - | - | - | - | - | PC Pin | - | - | - | 5V | Yes | Yes | - | - | - | - | - | - | - | EC09E | Vertical | Quadrature (Incremental) | Active | Alps Alpine | 4.5mm Dia Flatted End | - |
