cigen-CWR-140
CWR-140 rectangular connectors - board in, direct wire to board Series
cw-industriesThe CWR-140 series from CW Industries, Inc., are rectangular IDC (Insulation Displacement Contact) connectors designed for direct wire to board applications. These connectors feature a cover lip that can be positioned in different locations, offering flexibility in board design and assembly processes. If you're working on projects requiring high-density, reliable connections without soldering, these connectors are a solid choice. One thing worth noting is their versatility; the adjustable cover lip allows for easy insertion and removal of wires, making them ideal for prototyping and frequent rework scenarios. Engineers tend to reach for this when they need a quick and secure connection method for multiple wire gauges, which is common in many electronic assemblies. Another practical benefit is their compact size, which helps in optimizing space on PCBs where real estate is at a premium
The CWR-140 series from CW Industries, Inc., are rectangular IDC (Insulation Displacement Contact) connectors designed for direct wire to board applications. These connectors feature a cover lip that can be positioned in different locations, offering flexibility in board design and assembly processes. If you're working on projects requiring high-density, reliable connections without soldering, these connectors are a solid choice. One thing worth noting is their versatility; the adjustable cover lip allows for easy insertion and removal of wires, making them ideal for prototyping and frequent rework scenarios. Engineers tend to reach for this when they need a quick and secure connection method for multiple wire gauges, which is common in many electronic assemblies. Another practical benefit is their compact size, which helps in optimizing space on PCBs where real estate is at a premium
Series Images (1)
Documents & Media
Frequently Asked Questions
CWR-140 rectangular connectors - board in, direct wire to board - Part List
8 parts in total| Mfr Part # | Quantity Available | Price | Category | Standard Package | Color | Pitch | Packaging | Wire Gauge | Row Spacing | Mounting Type | Connector Type | Number of Rows | Cable Termination | Number of Positions | Features | Number of Positions Loaded | Contact Finish | Contact Finish Thickness | RoHS | Cable Pitch | Board-Side Pitch | Other Names |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CWR-140-40-0003 CW Industries | 70 | 1: $21.148 | - | 100 | Blue | 0.050" (1.27mm) | Bulk | 28-30 AWG, Stranded or Solid | 0.100" (2.54mm) | Through Hole | Ribbon Cable | 2 | IDC | 40 | Closed End, Strain Relief | All | Tin-Lead | 100µin (2.54µm) | - | - | - | Q865225 |
 CWR-140-40-0203 CW Industries | 124 | 1: $36.3069 | - | 100 | Blue | 0.050" (1.27mm) | Bulk | 28-30 AWG, Stranded or Solid | 0.100" (2.54mm) | Through Hole | Ribbon Cable | 2 | IDC | 40 | Closed End, Strain Relief | All | Tin | - | - | - | - | CPL40S |
CWR-140-10-0003 CW Industries | 100 | 1: $10.472 | - | 100 | Blue | 0.050" (1.27mm) | Bulk | 28-30 AWG, Stranded or Solid | 0.100" (2.54mm) | Through Hole | Ribbon Cable | 2 | IDC | 10 | Closed End, Strain Relief | All | Tin-Lead | 100µin (2.54µm) | Contains lead / RoHS non-compliant | 0.050" (1.27mm) | 0.200" (5.08mm) | - |
CWR-140-20-0003 CW Industries | 10 | 100: $11.8524 | - | 100 | Blue | 0.050" (1.27mm) | Bulk | 28-30 AWG, Stranded or Solid | 0.100" (2.54mm) | Through Hole | Ribbon Cable | 2 | IDC | 20 | Closed End, Strain Relief | All | Tin-Lead | 100µin (2.54µm) | Contains lead / RoHS non-compliant | 0.050" (1.27mm) | 0.200" (5.08mm) | - |
CWR-140-20-0203 CW Industries | 10 | 100: $11.8524 | - | 100 | Blue | 0.050" (1.27mm) | Bulk | 28-30 AWG, Stranded or Solid | 0.100" (2.54mm) | Through Hole | Ribbon Cable | 2 | IDC | 20 | Closed End, Strain Relief | All | Tin | 100µin (2.54µm) | Lead free / RoHS Compliant | 0.050" (1.27mm) | 0.200" (5.08mm) | - |
CWR-140-26-0003 CW Industries | 10 | 100: $14.0352 | - | 100 | Blue | 0.050" (1.27mm) | Bulk | 28-30 AWG, Stranded or Solid | 0.100" (2.54mm) | Through Hole | Ribbon Cable | 2 | IDC | 26 | Closed End, Strain Relief | All | Tin-Lead | 100µin (2.54µm) | Contains lead / RoHS non-compliant | 0.050" (1.27mm) | 0.200" (5.08mm) | - |
CWR-140-34-0003 CW Industries | 10 | 100: $16.184 | - | 100 | Blue | 0.050" (1.27mm) | Bulk | 28-30 AWG, Stranded or Solid | 0.100" (2.54mm) | Through Hole | Ribbon Cable | 2 | IDC | 34 | Closed End, Strain Relief | All | Tin-Lead | 100µin (2.54µm) | Contains lead / RoHS non-compliant | 0.050" (1.27mm) | 0.200" (5.08mm) | - |
CWR-140-20-0000 CW Industries | 10 | 100: $16.7824 | - | 100 | Blue | 0.050" (1.27mm) | Bulk | 28-30 AWG, Stranded or Solid | 0.100" (2.54mm) | Through Hole | Ribbon Cable | 2 | IDC | 20 | Closed End, Strain Relief | All | - | - | Contains lead / RoHS non-compliant | 0.050" (1.27mm) | 0.200" (5.08mm) | - |
