cigen-552-0711
552-0711 led lighting Series
dialightThe 552-0711 series from Dialight plc is a 5mm bi-level LED circuit board indicator designed for a wide range of applications where visual status indication is crucial. These indicators are commonly found in control panels, instrumentation, and various monitoring systems where clear, reliable lighting is essential. One thing worth noting is that these bi-level LEDs provide a distinct visual difference between the two levels of brightness, which helps in conveying different states more effectively. For instance, in a process control system, one level might indicate normal operation while the other could signal an alarm condition. This makes them particularly useful in environments where quick, accurate status assessment is critical. Engineers tend to reach for this when they need a compact, high-brightness indicator that can clearly differentiate between multiple operational states. The 552-0711 series is also known for its durability and long lifespan, making it a reliable choice for industrial and commercial applications where longevity and performance are key factors. If you're working on any project that requires robust, visually distinct status indicators, these bi-level LEDs a
The 552-0711 series from Dialight plc is a 5mm bi-level LED circuit board indicator designed for a wide range of applications where visual status indication is crucial. These indicators are commonly found in control panels, instrumentation, and various monitoring systems where clear, reliable lighting is essential. One thing worth noting is that these bi-level LEDs provide a distinct visual difference between the two levels of brightness, which helps in conveying different states more effectively. For instance, in a process control system, one level might indicate normal operation while the other could signal an alarm condition. This makes them particularly useful in environments where quick, accurate status assessment is critical. Engineers tend to reach for this when they need a compact, high-brightness indicator that can clearly differentiate between multiple operational states. The 552-0711 series is also known for its durability and long lifespan, making it a reliable choice for industrial and commercial applications where longevity and performance are key factors. If you're working on any project that requires robust, visually distinct status indicators, these bi-level LEDs a
Series Images (4)
Documents & Media
Frequently Asked Questions
552-0711 led lighting - Part List
6 parts in total| Mfr Part # | Quantity Available | Price | Category | Standard Package | RoHS | Packaging | Mounting Type | Product Category | Other Names | Current | Viewing Angle | Voltage Rating | Wavelength - Peak | Millicandela Rating | Color | Lens Style/Size | Lens Type | Configuration | Factory Pack Quantity | EU RoHS | Optic Size | Wavelength | Lamp Output | Luminous Flux | LED Forward Current | LED Forward Voltage | Power Dissipation (Max) | Current - Peak Pulse (10/1000us) | Lead Style | Lens Style | Mounting Style | Illumination Color | Number of Positions | Type | Series | Number of LEDs | Operating Temperature | Luminous Flux @ Current/Temperature | Lead Time | Subcategory | Industry Aliases | For Use With/Related Products |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 552-0711F Dialight | 30 | 1: $11.832 | - | 50 | RoHS Compliant | Bulk | Through Hole | LED Circuit Board Indicators | - | 20mA | 60 deg | 2.1V Green, 1.8V Red | 565nm, 660nm | 40mcd Green, 90mcd Red | Green/Red | Round with Domed Top, 5mm | Colorless Diffused | 2 Bi-Color LEDs, Bi-Level | 50 | Compliant | 5 mm | 660 nm, 565 nm | No | 40mcd|90mcd | 20 mA | 1.8 V, 2.1 V | 100 | 30/40 | Through Hole | Circular | Right Angle | Red/Green (x 2) | 4 | Bi-Level Bi-Color | 552 | 4 | 100 | 90 mcd, 40 mcd | - | - | - | - |
 552-0711-100F Dialight | 10 | 280: $8.024 | - | 50 | RoHS Compliant | Bulk | Through Hole, Right Angle | LED Circuit Board Indicators | 5520711100F | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
552-0711-806F Dialight | 10 | 140: $16.184 | - | 50 | RoHS Compliant | Bulk | Through Hole, Right Angle | LED Circuit Board Indicators | 5520711806F | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
552-0711-809F Dialight | 10 | 230: $10.268 | - | 50 | RoHS Compliant | Bulk | Through Hole, Right Angle | LED Circuit Board Indicators | 5520711809F | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
552-0711-004F Dialight | 10 | 87: $64.804 | - | 143 | RoHS Compliant | Bulk | Through Hole, Right Angle | LED Circuit Board Indicators | 5520711004F | 20mA | 60° | 2.1V Green, 1.8V Red | 565nm, 660nm | 40mcd Green, 90mcd Red | Green, Red | Round with Domed Top, 5mm | Diffused | 2 High | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 552-0711 Dialight | 0 | - | 50 | Contains lead / RoHS non-compliant | Bulk | Through Hole, Right Angle | - | - | 20mA | 60° | 2.1V Green, 1.8V Red | 565nm, 660nm | 40mcd Green, 90mcd Red | Green, Red (x 2) | Round with Domed Top, 5mm | Diffused | 2 High | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 365 Days | LED | 552-0711 | 552-0711F |
